High Speed Rubber Doors Model 885

High Speed Rubber Doors Model 885

Model 885 ADV-Xtreme high speed exterior rubber door is made with special reinforced rubber, perfect for large exterior openings or extreme applications. Constructed with 5 layers of NBR rubber and 4 layers of polyester weave, this door can withstand the pressure of up to 27.0 psf. High speed rubber doors are also designed to be low maintenance and include such features for safety as the breakaway impact detection and push button self-repair, along with plug and play wiring. The exterior high speed rubber door is built tough with rugged fabric material for extreme environments.


Ideal Applications Include:

Manufacturing / Heavy Manufacturing  |  Warehouse   |  Distribution Facilities  |  Mininig |   Auto and Transit   |  Parking Garages   |  Large Openings

Features

Standard ConstructionModel 885
OpeningsExterior
Max. Width30'
Max. Height30'
Max. Opening Speedup to 50” per second
Max. Closing Speedup to 40” per second
Breakaway Self-ResetYes
Curtain Material5 layers of NBR rubber with 4 layers of polyester weave
OperationDirect drive motor and gearbox system with field changeable universal handing and door stop safety device
Control PanelVariable frequency drive, self-diagnostic, programmable service reminders, pad-lockable fused disconnect NEMA 4X rated, cULus listed
Supply Voltages208V AC 3 PH
230V AC 3 PH
460V AC 3PH
575V AC 3 PH
Safety FeaturesObstruction Safety Detection
Reversing Sensing Edge
Wind Load*up to 27.0 psf

*Wind load is the ultimate pressure tested at door width of 19'.
(†Requires stand-alone mounted transformer)



Benefits

Rugged Construction

  • Multi-layered, reinforced rubber provides added strength without the weight
  • Ideal for harsh exterior conditions with a wind load of up to 27.0 psf
  • Nitrile butadiene rubber (NBR) provides resistance to petrochemicals for easy cleaning
  • Continuous curtain locks on both edges.

High Cycle, Low Maintenance Design

  • Springless design requires minimal interruption for maintenance
  • Patent-pending breakaway system design with impact detection and push button self-repair
  • Direct-mounted gear drive minimizes wear and tear
  • Variable frequency drive eliminates sudden jolts from door start/stop

Installer Friendly

  • Pre-assembled sub-assemblies for easier installation
  • Plug-and-play wiring reduces the need for a licensed electrician

Warranty

  • 5-Year Limited Warranty on drive motor and gearbox
  • 1-Year Limited Warranty on all other components
